Customer core requirements

Compliance with strict regulatory requirements in terms of aseptic operations, data integrity and stable reliability. The touch response is sensitive and error-proof; emphasis is placed on the reliability of 7×24-hour continuous production (MTBF > 50,000 hours) and rapid fault recovery (MTTR < 30 minutes).

Main technical indicators of industrial touch panels:

1. Display and Touch: 21.5-inch LCD screen, 10-point projected capacitive touch.

2. Interfaces and Expansion: Three interfaces (HDMI/DVI-D/DP), 3×USB 2.0 interfaces, 9 operation buttons with a diameter of 22mm.

3. Installation Method: Suspended arm installation.

4. Power Supply: DC 24V input

Product features of industrial touch panel:

1. Cantilever-style human-computer interaction design: The upper cantilever is installed and supports landscape display.

2. Operations and buttons: Integrated with 9 standard buttons with a diameter of 22mm (emergency stop/function keys are optional) and a keyboard tray, achieving a unified integration of physical quick operations and data input.

3. Ultra-long distance deployment: Supports three interfaces of HDMI/DVI/DP, with the maximum communication distance between the PC and the panel reaching up to 30 meters.

4. Industrial-grade robust protection: The front panel has an IP65 protection level, and the power supply has overcurrent, overvoltage, short-circuit protection, and anti-reverse connection functions.

5. Modular expansion capability: Built-in 3×USB2.0 interfaces, optional key lock switch, enhancing the security of operation permission management.

6. CE/FCC certification: Meets the electromagnetic compatibility requirements for industrial sites.
