Customer core requirements

Microsecond-level low latency and high-precision synchronization performance, perfectly compatible with mainstream CNC systems, EtherCAT standard protocols and various peripherals, without the need for additional adaptation; supports function customization and multi-process adaptation, with rich interfaces to meet the expansion needs of peripherals, long MTBF and supporting 24-hour continuous and reliable operation, and customizable buttons, fully adapting to the processing center operation requirements.

Main technical indicators of the EC-8106 control panel：

1. Bus type: EtherCAT (slave protocol)

2. Operating parameters: 63 mechanical switch buttons, 63 indicator lights.

3. Handwheel interface: 2 pulse handwheel interfaces (1 differential, 1 single-ended)

4. Installation and accessories: Embedded installation, 3P 5.08 power terminals, 7P/6P/4P plugs, key covers, M4 flange nuts, stickers, etc. are standard accessories.

5. Power supply: DC 12-24VDC input

Product Features of EC-8106 Control Panel：

1. Professional protocol compatibility: Supports EtherCAT slave protocol.

2. Rich operation control functions: Equipped with 63 mechanical switch buttons and 63 multi-color indicator lights.

3. Flexible I/O interface expansion: Provides 12 isolated digital inputs and 12 isolated digital outputs.

4. Safe and stable power configuration: Features polarity reverse protection and overvoltage protection functions.

5. Targeted stability design: The entire machine adopts anti-interference design.

6. Excellent durability and environmental adaptability: The key press life reaches 500,000 times. The mechanical structure is sturdy and durable, capable of withstanding the complex environment of industrial workshops.

7. EMC: CE/FCC certification
